3M 7010492019 | 10.000" Diameter x 1.000" Thickness Cutter Grinding Wheel

SKU: 45047159 Weight: 0.12 LBS Minimum Purchase: 1 unit
UPC: 00076308237943
$1,914.89 $1,589.36
(You save $325.53)
Shipping: Free Shipping

About This Item

3M CBN Resin Wheel 164BK wheels are used to generate the flute which is the helical or straight groove in the body of the cutting tools made of tool steel and high speed steel. This general purpose wheel offers high form retention and good cut rate during grinding operations.

The 3M CBN Resin Wheel 164BK line is specifically designed for the production and re-sharpening of high speed steel and tool steels cutting tools with the priority placed on holding form. The wheel used to generate the flute which is the helical or straight groove in the body of the tool. This process requires the highest level of quality that the 3M CBN Resin Wheel 163BK provides. Water based coolant is required when using this wheel.

3M provides a broad portfolio of superabrasive wheels used for your round tool relief and clearance angle applications. From short runs and re-sharpening to "lights-out" and long production runs, 3M has the wheel design to meet your needs.

Features:

  • Designed for water based coolants
  • Cubic boron nitride abrasive mineral provides fast cut rates at high temperatures
  • The resin bond system is designed to provide high form retention when fluting
  • Arbor holes are made to customer specifications, so you get exactly the size you need
  • Best used for grinding high speed steel, tool steels, and other hard to grind ferrous metals

Product Specifications
Manufacturer Part Number7010492019
Center Hole Diameter (Inch)1.9685"
Center Hole Diameter (mm)50.0mm
Overall Diameter (Inch)10.0"
Overall Diameter (mm)254.0mm
Overall Thickness (Inch)1.0"
Overall Thickness (mm)25.4mm
Wheel Type6A2C
Product FormWheel
Product Number164BK
