The replaceable head model allows for on-machine replacement, significantly reducing set-up and down time and allowing for multiple diameters within the same arbor reducing inventory requirements.
Features:
- A variety of leads provide tailored solutions for every applications
- Tight tolerances (+/- 0.0002") capable with expandable diameter head design
Product Specifications
| # MFG | 7000-MM-006 |
| Gage Length (mm) | 165mm |
| Length of Cut (mm) | 120mm |
| Maximum Diameter (Decimal Inch) | 1.5987" |
| Maximum Diameter (mm) | 40.609mm |
| Minimum Diameter (Decimal Inch) | 1.2839" |
| Minimum Diameter (mm) | 32.61mm |
| Modular Shank Size (mm) | 50mm |
| Series | 7000 |
| Shank Type | Modular |
| Length Type | Standard |
| Coolant | Radial Coolant |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Allied Machine and Engineering
Maximum Diameter (Decimal Inch):
1.5987"
Maximum Diameter (mm):
40.61mm
Minimum Diameter (Decimal Inch):
1.2839"
Minimum Diameter (mm):
32.61mm
Gage Length (mm):
165.00mm
Length of Cut (mm):
120.00mm
Shank Type:
Modular
