Product Specifications
Milling Diameter (Decimal Inch) | 0.31" |
Shank Diameter (Decimal Inch) | 0.312" |
Length of Cut (Decimal Inch) | 1.418" |
Overall Length (Decimal Inch) | 2.5" |
Number of Flutes | 4 |
Minimum Thread Size | M12 |
Depth to Diameter | 3X |
Cutting Direction | Left Hand |
Finish/Coating | AM210 |
Shank Type | Cylindrical |
Thread Style | Internal/External |
Flute Type | Helical |
Thread Standard | ISO |
Pitch | 1.75 |
Coolant Through | No |
Weldon Flat | No |
Material | Solid Carbide |
Harmon Code | 8209.00.0030 |
Weight (Lbs) | 0.01 |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Allied Machine and Engineering
Shank Diameter (Decimal Inch):
0.312"
Length of Cut (Decimal Inch):
1.418"
Overall Length (Decimal Inch):
2.5
Number of Flutes:
4
Finish/Coating:
AM210
Shank Type:
Cylindrical
Thread Type:
Internal/External
Thread Standard:
ISO
Pitch:
1.75
Through Coolant:
No
Material:
Solid Carbide
Ships:
From Partner Facility
