Features:
- Thread Per Inch :24
Product Specifications
| # MFG | TM31224M-3T2X |
| Cutter Diameter (mm) | 6.60mm |
| Length of Cut (mm) | 17.02mm |
| Overall Length (mm) | 64mm |
| Shank Diameter (mm) | 8.00mm |
| Minimum Thread Size | 5/16" |
| Number of Flutes | 3 |
| Pitch | 24 |
| Cutting Direction | Left Hand (M04) |
| Depth to Diameter | 2X |
| Shank Type | Cylindrical |
| Thread Standard | UN |
| Coolant Through | No |
| Coating | AM210 |
| Material | Carbide |
| Flute Type | Helical |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Allied Machine and Engineering
Mill Diameter (mm):
6.60mm
Shank Diameter (mm):
8mm
Length of Cut (mm):
17.02mm
Overall Length (mm):
64mm
Number of Flutes:
3
Minimum Thread Size:
5/16
Depth to Diameter:
2X
Cutting Direction:
Left Hand
Finish/Coating:
AM210
Shank Type:
Cylindrical
Thread Style:
Internal/External
Flute Type:
Helical
Thread Standard:
UN
Pitch:
24
Through Coolant:
No
Material:
Solid Carbide
Ships:
From Partner Facility
