| Catalog Number | PJC20-6 |
| Length (mm) | 61.00mm |
| Nominal Clamping Size (mm) | 6.00mm |
| Straight Collet Clamping OD (mm) | 20.00mm |
| Minimum Clamping Length (mm) | 39.00mm |
| Minimum Clamping Range (mm) | 6.00mm |
| Maximum Clamping Range (mm) | 6.00mm |
| Outer Diameter (mm) | 20.00mm |
| Straight Collet Nose OD (mm) | 27.00mm |
| Straight Collet Nose Length (mm) | 5.20mm |
| Collet Series | H-C20 |
| Sealed Coolant Capability | No |
| Jet Coolant Capability | No |
| Tapping Capability | No |
| Product Type | Reduction Sleeve |
