Revolving Handle
Modern square-design handle made of nylon thermoplastic with a threaded steel spindle. Revolving Handles have an internal bearing that allows the handle to remain fixed in your hand, for firm gripping while turning a Hand Wheel or crank. Threaded spindle has a hex socket for easy installation.
Application Information
Revolving Handles can be used to make custom crank handles.
Material
| Item | Material | Heat Treat | Finish | DFARS | RoHS |
| Body | Matte black nylon thermoplastic (textured surface for secure gripping, excellent impact resistance, operating temperatures to 230°F) | Yes | Yes | Yes | Yes |
| Threaded Spindle | Mild Steel | Yes | Zinc Plated Clear Chromate, Molded In | Yes | ✔/td> |
Parts Specification
| Handle Size | A (Inch) | B (Inch) | C Thread | D Diameter (Inch) | E Diameter (Inch) | F (Inch) | G (Inch) |
| Size 1 | 1.67" | 0.47" | 1/4-20 | 0.71" | 0.39" | 3mm" | 0.10" |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Carr Lane
Ships:
From Manufacturer
