Dormer B41110.0 | 0.3937" Diameter x 6.6142" OAL Bright Coated Chucking Reamer

$214.89
Brand:
Dormer
Reamer Diameter (Inch):
25/64"
Reamer Diameter (Decimal Inch):
0.3937"
Reamer Diameter (mm):
10mm
Overall Length (Inch):
6-39/64"
Overall Length (Decimal Inch):
6.6142"
Overall Length (mm):
168mm
Flute Length (Inch):
1-1/2"
Flute Length (Decimal Inch):
1.5000"
Flute Length (mm):
38mm
Material:
HM
Finish/Coating:
Bright
SKU:
10114736
Weight:
4.23 LBS
Minimum Purchase:
1 unit
Shipping:
Free Shipping

Machine reamer with left hand slow spiral flutes which are extremely unequally spaced and a Morse taper shank, diameter 10.00mm with an overall length of 168mm, a flute length of 38mm and 102.5mm reach with neck relief, according to DIN 8094 standard for reaming precise holes within H7 tolerance, carbide head with bright finish for machining free machining, plain carbon, alloy and tool steel, grey, malleable, ductile and compacted graphite cast-iron, wrought and cast aluminium and copper or copper alloys.


Product Specifications
EDP Number0053126
Flute Count6
Cutting Diameter (Inch)0.3937"
Body Length (mm)102.5mm
Overall Length (Inch)6.6142"
Material CodeHM
Cutting DirectionRight Hand
CoatingBright
Surface ColorBright Silver
