Dormer C29910.0 | 0.3937" Diameter x 2.8346" OAL 4 Flute Bright Coated Square End Mill

$41.38
Ships:
From Partner Facility
Ships:
From Partner Facility
SKU:
25139367
UPC:
7320760064313
Weight:
1.48 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout

C299 4-flute milling cutters can be used for plunging, ramping and profile milling in stainless steels, steels and cast iron and are manufactured from the best powder metal high speed cobalt, providing great performance and a long tool life. They have a bright finish which ensures a clean, accurate result by stopping workpiece material from sticking to the cutting edges of the tool. The medium length flute provides high rigidity for general profile milling applications. Finally, the 45 degree helix means C299 milling cutters are designed for high performance when machining heat resistant materials on CNC machines.


Product Specifications
Usable Length (mm)31.5mm
Max Depth of Cut (mm)22mm
Connection Diameter (Inch)0.3937"
Cutting Diameter (Inch)0.3937"
Overall Length (Inch)2.8346"
Material CodeHSS-E-PM
Radial Rake Angle12
No of Flute4
Flute Helix Angle45
CoatingBright
Surface ColorBright Silver
