C907 4- flute end mills have a special Alcrona coating which in.]creases the service life of the tool and improves performance milling materials which are difficult to machine. Thanks to the 45 degree helix, you will see great performance when machining heat resistant materials on CNC machines, whilst the medium length flute design gives greater rigidity for general milling applications. C907 end mills can be used for ramping, profile milling and plunging in steels, stainless steels and cast iron.
| Usable Length (mm) | 43.5mm |
| Max Depth of Cut (mm) | 32mm |
| Connection Diameter (Inch) | 0.6299" |
| Cutting Diameter (Inch) | 0.6299" |
| Overall Length (Inch) | 3.622" |
| Material Code | HSS-E-PM |
| Radial Rake Angle | 12 |
| No of Flute | 4 |
| Flute Helix Angle | 45 |
| Coating | ALCRONA |
| Surface Color | Black-Deep Purple |
