Spiral point tap with chamfer form B with a 3.5-5xP plug lead, for ISO-Metric thread M4 with 0.70mm pitch and 6H class of fit, dimensions according to ANSI standard with 0.1680" shank and 0.1310" square drive, powder metallurgical HSS-E with steam tempered surface finish for 2.5xD through hole threading in general purpose applications.
| Connection Diameter (Inch) | 0.168" |
| Overall Length (Inch) | 2.125" |
| No of Flutes | 2 |
| Usable Length (Inch) | 0.6526" |
| Thread Pitch (mm) | 0.7mm |
| Thread Diameter Size | 4 |
| Material Code | HSS-E-PM |
| Thread Tolerance Class | 6H |
| Threading Length (Inch) | 0.2484" |
| Cutting Direction | Right Hand |
| Coating | Steam Tempered |
| Tap Chamfer Style | B 3.5-5 |
| Surface Color | Black |
| Thread Form | M-Metric coarse |
| Country of origin | Brazil |
