Spiral point tap with chamfer form B with a 3.5-5xP plug lead, for Unified National Fine thread UNF 7/8" with 14 TPI and 2B class of fit, dimensions according to ISO 529 standard with 16.0mm shank and 12.5mm square drive, powder metallurgical HSS-E with steam tempered surface finish for 2.5xD through hole threading in general purpose applications.
| Connection Diameter (Inch) | 0.6299" |
| Overall Length (Inch) | 4.6457" |
| Clamping Width (mm) | 12.5mm |
| Thread Diameter (mm) | 22.225mm |
| No of Flutes | 4 |
| Clamping Length | 16 |
| Thread Diameter Size | 7/8 |
| Threading Length (mm) | 29mm |
| Material Code | HSS-E-PM |
| Thread Tolerance Class | 2B |
| Cutting Direction | Right Hand |
| Coating | Steam Tempered |
| Tap Chamfer Style | B 3.5-5 |
| Surface Color | Black |
| Thread Form | UNF-Unified Fine |
| Country of origin | India |
