Spiral flute tap with chamfer form C with a 2-3xP semi-bottoming lead, for Unified National Fine thread UNF 9/16" with 18 TPI and 2B class of fit, dimensions according to ISO 529 standard with 11.2mm shank and 9.0mm square drive, powder metallurgical HSS-E with steam tempered surface finish and 45 Degree helix angle for 2.5xD blind hole threading in general purpose applications.
| Connection Diameter (Inch) | 0.4409" |
| Overall Length (Inch) | 3.7402" |
| Clamping Width (mm) | 9mm |
| Thread Diameter (mm) | 14.288mm |
| No of Flutes | 3 |
| Flute Helix Angle | 45 |
| Clamping Length | 12 |
| Thread Diameter Size | 9/16 |
| Threading Length (mm) | 24mm |
| Material Code | HSS-E-PM |
| Thread Tolerance Class | 2B |
| Cutting Direction | Right Hand |
| Coating | Steam Tempered |
| Tap Chamfer Style | C 2-3 |
| Surface Color | Black |
| Thread Form | UNF-Unified Fine |
| Country of origin | India |
