Dormer E397M4 | 4" Thread Diameter Size x 12.00mm Thread Length x 63.00mm OAL TiCN Coated HSS-E-PM Spiral Point Tap

$36.85 $17.69
(You save $19.16)
Brand:
Dormer
Thread Diameter Size:
4"
Thread Length (Inch):
15/32"
Thread Length (Decimal Inch):
0.4700"
Thread Length (mm):
12.00mm
Material:
HSS-E-PM
Finish/Coating:
TiCN
interval quantity:
1
SKU:
18020218
UPC:
Weight:
0.02 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
Dormer E397M4 | 4" Thread Diameter Size x 12.00mm Thread Length x 63.00mm OAL TiCN Coated HSS-E-PM Spiral Point Tap

Thread size M4 mm x 0.7 mm, with thread tolerance class 93707, and maximum threading depth 10 mm.


Product Specifications
Manufacturer Part NumberE397M4
Connection Diameter (mm)4.50mm
Connection Diameter (Decimal Inch)0.177"
Usable Length (mm)21.00mm
Thread Diameter Size4"
Overall Length (Decimal Inch)2.480"
Overall Length (mm)63.00mm
Thread Length (mm)12.00mm
Thread Pitch (Decimal Inch)0.028"
Thread Pitch (mm)0.70mm
Premachined Hole Diameter (mm)3.30mm
Usable Length (Decimal Inch)0.827"
Clamping Length (mm)6.00mm
Clamping Width (mm)3.40mm
Thread Length (Decimal Inch)0.472"
Clamping Length (Decimal Inch)0.236"
Clamping Width (Decimal Inch)0.134"
Premachined Hole Diameter (Decimal Inch)0.130"
Number of Flutes3
Tap Chamfer StyleB 3.5 - 5
Thread FormM - Metric Coarse
Flute GeometrySpiral Point Geometry
Cutting DirectionRight Hand
Basic Standard GroupDIN 371 LE 10, DIN 376 GE 12
MaterialHSS-E-PM
CoatingTiCN
Product TypeSpiral Point Tap
Country of OriginBrazil
