Features:
- Designed for high performance milling in tougher materials
- External
Product Specifications
| Decimal Size (Inch) | 0.625" |
| End Style | Corner Radius |
| End Type | Finisher |
| Size | 5/8" |
| Applicable Material | Steel, Cast Iron, Hardened Materials |
| Type | Corner Radius |
| Length Group | Standard |
| Features: | Modified flute form and variable spacing for high performance milling |
| Coating | TIALN |
| Material | Carbide |
| Number of Flutes | 4 |
| Helix Angle (Degrees) | 50 Degree |
| Shank Diameter (Inch) | 5/8" |
| Shank Tolerance | h5 |
| Shank Style | HA |
| Overall Length (Inch) | 3-1/2" |
| Flute Length (Inch) | 1-1/4" |
| Flute Direction | Right Hand |
| Corner Radius | 0.0437" |
| Application | Finisher |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Emuge
Mill Diameter (Inch):
5/8"
Mill Diameter (Decimal Inch):
0.6300"
Mill Diameter (mm):
15.88mm
Number of Flutes:
4
Corner Radius (Inch):
3/64"
Corner Radius (Decimal Inch):
0.0437"
Corner Radius (mm):
1.11mm
Length of Cut (Inch):
1-1/4"
Length of Cut (Decimal Inch):
1.2500"
Length of Cut (mm):
31.75mm
Material:
Carbide
Finish/Coating:
TIALN
Shank Diameter (Inch):
5/8"
Shank Diameter (Decimal Inch):
0.6300"
Shank Diameter (mm):
15.88mm
Application:
Finisher
Overall Length (Inch):
3-1/2"
Overall Length (Decimal Inch):
3.5000"
