Features:
| Chamfer | 1.5 -2 P |
| Chamfer Form | E |
| Pitch | 10 |
| Size | 3/4" |
| Thread Limit | 2B |
| Thread Standard | UNC |
| Applicable Material | Long Chipping Materials |
| Application | Blind Hole |
| Coolant Fed | No |
| Coating | TIN |
| Material | HSSE |
| Type | Enorm Z/E |
| Length Group | ANSI Length |
| Flutes | 4 |
| Helix Angle (Degrees) | 45 Degree |
| Shank Diameter (mm) | 0.590" |
| Dimension Standards | ANSI/ANSI |
| Shank Tolerance | h9 |
| Overall Length (mm) | 4.252" |
| Thread Length (mm) | 1.181" |
| Flute Direction | Right Hand |
