Features:
| Chamfer | 2 -3 P |
| Chamfer Form | C |
| Pitch | 0.5 |
| Size | M 4 |
| Thread Limit | 6H |
| Thread Standard | MF |
| Applicable Material | Alloyed Steel & Long Chipping Materials |
| Application | Blind Hole |
| Coolant Fed | No |
| Coating/Finish | TiN |
| Material | HSSE |
| Type | Enorm |
| Length Group | DIN Length |
| Number of Flutes | 3 |
| Helix Angle (Degrees) | 35 Degree |
| Shank Diameter (mm) | 4.5 mm |
| Dimension Standards | DIN/DIN |
| Shank Tolerance | h9 |
| Overall Length (mm) | 63 mm |
| Thread Length (mm) | 5 mm |
| Flute Direction | Right Hand |
