Features:
- The Druck Steel roll form tap for the chipless production of internal threads, blind and though hole
- Steel Alloys & Long Chipping Materials
- TICN coated for additional wear resistance
- DIN / ANSI taps manufactured to DIN length for extra reach and ANSI shanks
Product Specifications
| Manufacturer Part Number | BU931400.5709 |
| Thread Size | LK 6-40 |
| Thread Diameter Size | LK 6 |
| Thread Standard | LK-UNF |
| Thread per Inch (TPI) | 40 TPI |
| Tap Square (Decimal Inch) | 0.110" |
| Thread Length (Decimal Inch) | 0.472" |
| Overall Length (Decimal Inch) | 2.205" |
| Shank Machine Side Connection Diameter (Decimal Inch) | 0.141" |
| Thread Tolerance Class | BT |
| Tap Chamfer | 1.5-2 P |
| Tap Chamfer Form | E |
| Class of Fit | LK |
| Dimensional Standards | DIN/ANSI |
| Shank Tolerance | h9 |
| Flute Direction | Straight |
| Group Length | DIN Length |
| Coolant Supply Property | External |
| Coolant Fed | No |
| Cutting Edge Material | HSSE |
| Coating | TIN |
| Tool Type | Roll Form - Druck |
| Application | Form Taps |
| Product Type | Thread Forming Tap |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Emuge
Shank Diameter (Decimal Inch):
0.1410"
Cutting Edge Material:
HSSE
Thread Length (Decimal Inch):
0.4720"
Thread Size:
LK 6-40
Thread Standard:
LK-UNF
Threads per Inch (TPI):
40 TPI
Flute Direction:
Straight
Finish/Coating:
TiN
Tool Type:
Roll Form - Druck
Class of Fit:
LK
Application:
Form Taps
Overall Length (Decimal Inch):
2.2050"
