| Chamfer | 2 -3 P |
| Chamfer Form | C |
| Pitch | 3 |
| Size | M 48 |
| Thread Limit | 6HX |
| Thread Standard | MF |
| Application | Through and Blind Hole |
| Coolant Fed | No |
| Coating/Finish | NE2 |
| Material | HSSE |
| Number of Flutes | 6 |
| Helix Angle (Degrees) | 0 Degree |
| Shank Diameter (mm) | 36 mm |
| Dimension Standards | DIN/DIN |
| Shank Tolerance | h9 |
| Overall Length (mm) | 225 mm |
| Thread Length (mm) | 50 mm |
| Flute Direction | Straight |
