C3179401.0277-C

Emuge C3179401.0277 | MF M10x1.25mm Thread Size x 16.00mm Length x 7.00mm Shank x 100.00mm OAL 3 Flute TICN Coated HSSE Straight Flute Tap

SKU: 15042997 Weight: 0.06 LBS Minimum Purchase: 1 unit
UPC:
$223.81 $219.33
(You save $4.48)
Ships: From Manufacturer
Shipping: Calculated at Checkout

About This Item

Features:

  • Speed taps are able to operate at higher cutting speeds than conventional designs. Rekord A-Speed is a straight flute design for high speed tapping in short chipping materials in through & blind hole applications
  • Longer tool life and more consistent thread quality

Product Specifications
Chamfer2 -3 P
Chamfer FormC
Pitch1.25
SizeM 10
Thread Limit6HX
Thread StandardMF
Applicable MaterialShort Chipping Materials
ApplicationThrough Hole
Coolant FedRadial
Coating/FinishTICN
MaterialHSSE
TypeRekord A-Speed
Length GroupDIN Length
Number of Flutes3
Helix Angle (Degrees)0 Degree
Shank Diameter (mm)7 mm
Dimension StandardsDIN/DIN
Shank Toleranceh9
Overall Length (mm)100 mm
Thread Length (mm)22 mm
Flute DirectionStraight
