Features:
| Chamfer | 2 -3 P |
| Chamfer Form | C |
| Pitch | 20 |
| Size | 7/16" |
| Thread Limit | 2BX |
| Thread Standard | UNC |
| Applicable Material | Steel Alloys and Short Chipping Materials |
| Application | Blind Hole |
| Coolant Fed | No |
| Coating/Finish | TIN |
| Material | HSSE |
| Type | Rekord D - Speed |
| Length Group | DIN Length |
| Number of Flutes | 3 |
| Helix Angle (Degrees) | 15 Degree |
| Shank Diameter (mm) | 0.323" |
| Dimension Standards | DIN/ANSI |
| Shank Tolerance | h9 |
| Overall Length (mm) | 3.937" |
| Thread Length (mm) | 0.866" |
| Flute Direction | Right Hand |
