Features:
- Rekord D-Z tap is a slow spiral design for blind holes, especially automatic lathes and multi-spindle machines. Designed with internal coolant supply, this tap type will help to solve chip problems
- Longer tool life and more consistent thread quality
Product Specifications
| Chamfer | 2 -3 P |
| Chamfer Form | C |
| Pitch | 18 |
| Size | 5/8" |
| Thread Limit | 2BX |
| Thread Standard | UNF |
| Applicable Material | Steel Alloys & Long Chipping Materials |
| Application | Blind Hole |
| Coolant Fed | Axial |
| Coating/Finish | TIN |
| Material | HSSE |
| Type | Rekord D-Z |
| Length Group | DIN Length |
| Number of Flutes | 3 |
| Helix Angle (Degrees) | 15 Degree |
| Shank Diameter (mm) | 0.480" |
| Dimension Standards | DIN/ANSI |
| Shank Tolerance | h9 |
| Overall Length (mm) | 3.937" |
| Thread Length (mm) | 0.866" |
| Flute Direction | Right Hand |
