Features:
| Cutter Diameter (Inch) | 0.496" |
| Pitch | 11 |
| Size | 5/8" |
| Thread Standard | UNC |
| Applicable Material | Steel, Stainless Steel, Cast Iron, Aluminum, Titanium |
| Application | Full Profile |
| Type | GFI / SHUR-THREAD |
| Length Group | 2 x D |
| Coolant Fed | No |
| Finish/Coating | TICN |
| Material | Carbide |
| Number of Flutes | 4 |
| Helix Angle (Degrees) | 15 Degree |
| Shank Diameter (Inch) | 1/2" |
| Dimension Standards | ASME B1.1 |
| Shank Tolerance | h6 |
| Shank Style | HB |
| Overall Length (Inch) | 3.75" |
| Flute Length (Inch) | 1.316" |
| Flute Spiral Direction | Right Hand, Left Hand |
