Features:
| Cutter Diameter (Inch) | 0.248" |
| Pitch | 18 |
| Size | 5/16" |
| Thread Standard | UNC |
| Applicable Material | Steel, Stainless Steel, Cast Iron, Aluminum, Titanium |
| Application | Single Plane |
| Type | ZGF-I /THREADS-ALL |
| Length Group | 3 x D |
| Coolant Fed | Axial |
| Finish/Coating | TICN |
| Material | Carbide |
| Number of Flutes | 4 |
| Helix Angle (Degrees) | 0 Degree |
| Shank Diameter (Inch) | 5/16" |
| Dimension Standards | ASME B1.1 |
| Shank Tolerance | h6 |
| Shank Style | HB |
| Overall Length (Inch) | 2.563" |
| Flute Length (Inch) | 0.937" |
| Flute Spiral Direction | Right Hand, Left Hand |
