Features:
- Gigant-IC indexable insert body for large diameter threading
- Economical solution for high production threading
Product Specifications
| Cutter Diameter (Inch) | 1.102" |
| Size | #11 |
| Application | Indexable Threading |
| Type | Gigant-IC Body |
| Coolant Fed | Radial |
| Finish/Coating | no |
| Material | Steel |
| Number of Flutes | 5 inserts |
| Shank Diameter (Inch) | 1 1/2" |
| Dimension Standards | ASME B94.19 |
| Shank Style | Weldon |
| Overall Length (Inch) | 5.945" |
| Flute Length (Inch) | 3.543" |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Emuge
Cutting Diameter (Decimal Inch):
1.1020"
Shank Diameter (Inch):
1-1/2"
Cutting Edge Material:
Steel
Flute Length (Decimal Inch):
3.5430"
Finish/Coating:
Bright
Tool Type:
Gigant-IC Body
Overall Length (Decimal Inch):
5.9450"
interval quantity:
1
