It's designed to withstand a variety of materials, including titanium, hardened steels, stainless steels, steels, cast iron, and brass & copper. Its robust notched cam point and 30 degree spiral allows for higher feed rates and increased tool life. The 1500 Notched Cam Point has 2-flutes and is stocked uncoated, with TiAlN coating. Get started with The Notched Cam Point drill!
| Manufacturer Part Number | 13221 |
| Cutting Diameter (Decimal Inch) | 0.082" |
| Cutting Diameter (mm) | 2.08mm |
| Shank Diameter (Decimal Inch) | 0.082" |
| Shank Diameter (mm) | 2.08mm |
| Cutting Flute Length (Inch) | 3/8" |
| Cutting Flute Length (Decimal Inch) | 0.375" |
| Cutting Flute Length (mm) | 9.53mm |
| Overall Length (Inch) | 1-1/2" |
| Overall Length (Decimal Inch) | 1.500" |
| Overall Length (mm) | 38.10mm |
| Number of Flutes | 2 |
| Helix Angle (Degree) | 30.00 Degree |
| Point Include Angle (Degree) | 135.00 Degree |
| Length | Stub |
| Flute Spiral | Right Hand |
| Cutting Direction | Right Hand |
| End Type | Notched |
| Coating | TiAlN |
| Series | 1500 |
| Product Type | Screw Machine Length Drill Bit |
