Features
| Cutting Diameter (Decimal Inch) | 0.4844" |
| Cutting Diameter (mm) | 12.30mm |
| Cutting Diameter (Inch) | 31/64" |
| Cutting Flute Length (Decimal Inch) | 3.3750" |
| Cutting Flute Length (mm) | 85.73mm |
| Cutting Flute Length (Inch) | 3-3/8" |
| Shank Diameter (Decimal Inch) | 0.5000" |
| Shank Diameter (mm) | 12.70mm |
| Shank Diameter (Inch) | 1/2" |
| Overall Length (Decimal Inch) | 5.0000" |
| Overall Length (mm) | 127.00mm |
| Overall Length (Inch) | 5" |
| Cleared Length (Decimal Inch) | 2.8750" |
| Cleared Length (mm) | 73.00mm |
| Coating/Finish | FC7 |
| Metric/Inch | Inch |
| Number of Flutes | 2 |
| Helix Angle (Degrees) | 30 |
| Flute Spiral Direction | Right Hand |
| Direction of Cut | Right Hand |
| Point End Type | Notched |
| End Type Character Designation | N |
| Point Include Angle | 144 |
| End Type | Single End |
| Coolant Through | Coolant Through |
| Weldon Flat | No |
| Length | Standard |
| Length Designator | 5xD |
