Features
| Cutting Diameter (Decimal Inch) | 0.4375" |
| Cutting Diameter (mm) | 11.11mm |
| Cutting Diameter (Inch) | 7/16" |
| Cutting Flute Length (Decimal Inch) | 2.8750" |
| Cutting Flute Length (mm) | 73.03mm |
| Cutting Flute Length (Inch) | 2-7/8" |
| Shank Diameter (Decimal Inch) | 0.4375" |
| Shank Diameter (mm) | 11.11mm |
| Shank Diameter (Inch) | 7/16" |
| Overall Length (Decimal Inch) | 4.5000" |
| Overall Length (mm) | 114.30mm |
| Overall Length (Inch) | 4-1/2" |
| Coating/Finish | Uncoated |
| Metric/Inch | Inch |
| Number of Flutes | 3 |
| Helix Angle (Degrees) | 30 |
| Flute Spiral Direction | Right Hand |
| Direction of Cut | Right Hand |
| Point End Type | Thinned |
| End Type Character Designation | T |
| Point Include Angle | 150 |
| End Type | Single End |
| Coolant Through | Non Coolant Through |
| Weldon Flat | No |
| Length | Standard |
| Length Designator | 5xD |
