Features
| Cutting Diameter (Decimal Inch) | 0.1360" |
| Cutting Diameter (mm) | 3.45mm |
| Diameter (Wire) | 29 |
| Cutting Flute Length (Decimal Inch) | 1.3750" |
| Cutting Flute Length (mm) | 34.93mm |
| Cutting Flute Length (Inch) | 1-3/8" |
| Shank Diameter (Decimal Inch) | 0.1360" |
| Shank Diameter (mm) | 3.45mm |
| Overall Length (Decimal Inch) | 2.5000" |
| Overall Length (mm) | 63.50mm |
| Overall Length (Inch) | 2-1/2" |
| Coating/Finish | Uncoated |
| Metric/Inch | Inch |
| Number of Flutes | 3 |
| Helix Angle (Degrees) | 30 |
| Flute Spiral Direction | Right Hand |
| Direction of Cut | Right Hand |
| Point End Type | Thinned |
| End Type Character Designation | T |
| Point Include Angle | 150 |
| End Type | Single End |
| Coolant Through | Non Coolant Through |
| Weldon Flat | No |
| Length | Standard |
| Length Designator | 7xD |
