Fullerton Tool 30913 | 0.0230" Diameter x 1/8" Shank x 0.0690" LOC x 1-1/2" OAL 2 Flute Uncoated Solid Carbide Square End Mill

$26.16 $16.48
(You save $9.68)
Ships:
From Partner Facility
Brand:
Fullerton Tool
Mill Diameter (Decimal Inch):
0.0230"
Number of Flutes:
2
Length of Cut (Decimal Inch):
0.0690"
Length of Cut (mm):
1.75mm
Shank Diameter (inch):
1/8"
Shank Diameter (Decimal Inch):
0.1250"
Shank Diameter (mm):
3.18mm
Material:
Solid Carbide
Finish/Coating:
Uncoated
Single or Double End:
Single
Cutting Direction:
Right Hand
Flute Direction:
Right Hand
Center Cutting:
Yes
Ships:
From Partner Facility
SKU:
25004337
UPC:
Weight:
0.01 LBS
Shipping:
Calculated at Checkout
Fullerton Tool 30913 | 0.0230" Diameter x 1/8" Shank x 0.0690" LOC x 1-1/2" OAL 2 Flute Uncoated Solid Carbide Square End Mill

Features

  • The 3215SM Sub-Miniature is a 2-flute, general purpose end mill designed for use in titanium, super alloys, stainless steels, steels, cast iron, brass & copper, and low si aluminum
  • It's offered in a variety of configurations and is available with single-end and double-end designs
  • The 3215SM Sub-Miniature end mill is stocked uncoated and with TiAlN, TiCN, and TiN coatings

Product Specifications
Cutting Diameter (Decimal Inch) 0.0230"
Cutting Diameter (mm) 0.58mm
Cutting Flute Length (Decimal Inch) 0.0690"
Cutting Flute Length (mm) 1.75mm
Shank Diameter (Decimal Inch) 0.1250"
Shank Diameter (mm) 3.18mm
Shank Diameter (Inch) 1/8"
Overall Length (Decimal Inch) 1.5000"
Overall Length (mm) 38.10mm
Overall Length (Inch) 1-1/2"
Coating/Finish Uncoated
Metric/Inch Inch
Number of Flutes 2
Helix Angle (Degrees) 30
Flute Spiral Direction Right Hand
Direction of Cut Right Hand
Point End Type Square
End Type Character Designation S
End Type Single End
Coolant Through Non Coolant Through
Weldon Flat No
Length Sub-Miniature
Length Designator SM



Warning:

This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.

For more information, visit www.P65Warnings.ca.gov

Warning:

This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.

For more information, visit www.P65Warnings.ca.gov

Brand:
Fullerton Tool
Mill Diameter (Decimal Inch):
0.0230"
Number of Flutes:
2
Length of Cut (Decimal Inch):
0.0690"
Length of Cut (mm):
1.75mm
Shank Diameter (inch):
1/8"
Shank Diameter (Decimal Inch):
0.1250"
Shank Diameter (mm):
3.18mm
Material:
Solid Carbide
Finish/Coating:
Uncoated
Single or Double End:
Single
Cutting Direction:
Right Hand
Flute Direction:
Right Hand
Center Cutting:
Yes
Ships:
From Partner Facility
