Fullerton Tool 33476 | 1" Diameter x 1" Shank x 2" LOC x 4" OAL 3 Flute TiAlN Solid Carbide Radius End Mill

About This Item

Features

• The 3335 Alloy Steel Rougher is a 3-flute, general purpose end mill designed for slotting, pocketing, and roughing in various alloy steels
• Its unique flute geometry and corner radius allows for increased chip loads, strength, and added tool life
• The 3335 Alloy Steel Rougher is stocked with TiAlN coating

Product Specifications

Cutting Diameter (Decimal Inch)	1"
Cutting Diameter (mm)	25.40mm
Cutting Diameter (Inch)	1"
Cutting Flute Length (Decimal Inch)	2.0000"
Cutting Flute Length (mm)	50.80mm
Cutting Flute Length (Inch)	2"
Shank Diameter (Decimal Inch)	1"
Shank Diameter (mm)	25.40mm
Shank Diameter (Inch)	1"
Overall Length (Decimal Inch)	4.0000"
Overall Length (mm)	101.60mm
Overall Length (Inch)	4"
Coating/Finish	TIALN
Metric/Inch	Inch
Number of Flutes	3
Helix Angle (Degrees)	35
Flute Spiral Direction	Right Hand
Direction of Cut	Right Hand
Point End Type	Corner Radius
End Type Character Designation	R
Radius (Decimal Inch)	0.0300"
Radius (mm)	0.76mm
End Type	Single End
Coolant Through	Non Coolant Through
Weldon Flat	No
Length	Standard
Length Designator	SD
