Features
- The 3600 Force is a high performance end mill available with 5, 7, or 9-flutes
- It produces excellent surface finishes and chip control and its optimized geometry allows for high feed rates in stainless steels, super alloys, and titanium
- The 3600 Force is stocked with FC-20 coating
Product Specifications
| Mill Diameter (Inch) | 5/8" |
| Cutting Flute Length (Inch) | 3/4" |
| Shank Diameter (Inch) | 5/8" |
| Overall Length (Inch) | 3-1/2" |
| Mill Diameter (Decimal Inch) | 0.6250" |
| Cutting Flute Length (Decimal Inch) | 0.7500" |
| Shank Diameter (Decimal Inch) | 0.6250" |
| Overall Length (Decimal Inch) | 3.5000" |
| Mill Diameter (mm) | 15.88mm |
| Cutting Flute Length (mm) | 19.05mm |
| Shank Diameter (mm) | 15.88mm |
| Overall Length (mm) | 88.90mm |
| Finish/Coating | FC20 |
| Number of Flutes | 9 |
| Helix Angle | 0 Degree |
| Flute Spiral Direction | Right Hand Spiral |
| Cutting Direction | Right Hand Cutting |
| Coolant Thorugh (Yes/No) | No |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Fullerton Tool
Mill Diameter (Inch):
5/8"
Mill Diameter (Decimal Inch):
0.6250"
Mill Diameter (mm):
15.88mm
Number of Flutes:
9
Length of Cut (Inch):
3/4"
Length of Cut (Decimal Inch):
0.7500"
Length of Cut (mm):
19.05mm
Material:
Solid Carbide
Finish/Coating:
FC20
Shank Diameter (Inch):
5/8"
Shank Diameter (Decimal Inch):
0.6250"
Shank Diameter (mm):
15.88mm
Application:
Stainless Steels, Super Alloys, and Titanium
Single or Double End:
Single
Overall Length (Inch):
3-1/2"
Overall Length (Decimal Inch):
3.5000"
Overall Length (mm):
88.90mm
Helix Angle:
0 Degree
Flute Direction:
Right
Cutting Direction:
Right
Series:
3600 Force
Ships:
From Partner Facility
