GS Tooling 531454 | 4.000" Projection CAT50 Size ER32 Collet Chuck

SKU: 55007135 Weight: 8.25 LBS Minimum Purchase: 1 unit
UPC:
$249.53 $169.68
(You save $79.85)
Shipping: Calculated at Checkout

About This Item

Features
  • DIN Coolant option-standard
  • All ground body
  • Factory balanced to save spindle life, tool life and increased productivity
  • Premium balanced to G2.5 @ 30,000 RPM
  • Threaded through holes for a back-up screw (tool stop) or coolant through when removed

Product Specifications
Manufacturer Part Number531454
Collet SystemER
Collet SeriesER32
Shank TypeTaper Shank
Taper SizeCAT50
Projection (Decimal Inch)4"
Minimum Collet Capacity (Decimal Inch)0.078"
Maximum Collet Capacity (Decimal Inch)0.787"
Balanced to (RPM)25000 RPM
Collet Nut Diameter (Decimal Inch)1.97"
Seat Depth (Decimal Inch)1.34"
Tightening Torque (Nm)169.5
Product TypeCollet Chuck
