GS Tooling 531768 | CAT40 Size SA25 Collet Chuck

Name: GS Tooling 531768 | CAT40 Size SA25 Collet Chuck
Brand: GS Tooling
SKU: 55021689
Price: 203.52 USD
Availability: InStock

SKU: 55021689 Weight: 3.40 LBS Minimum Purchase: 1 unit

$203.52

Total Price: $203.52

Quantity:

Shipping: Calculated at Checkout

About This Item

Features

DIN Coolant through the flange at no extra charge
Run out accuracy is>5µm at 4xD of the cutting tool shank
Each chuck comes with a collet extractor
Complete with certificate
CAT40 Premium balanced to 20,000 RPM
CAT50 Premium balanced to 15,000 RPM
8 degree tapered collet seats deeper in the body of the holder providing increased rigidity. This results in concentricity and stronger gripping power

Product Specifications

Manufacturer Part Number	531768
Collet System	Single Angle
Collet Series	SA25
Shank Type	Taper Shank
Taper Size	CAT40
Projection (Decimal Inch)	3.54"
Minimum Collet Capacity (Decimal Inch)	0.63"
Maximum Collet Capacity (Decimal Inch)	1"
Balanced to (RPM)	20000 RPM
Product Type	Collet Chuck
