Product Specifications
| Head Diameter (Decimal Inch) | 0.2500" |
| Head Diameter (Inch) | 1/4" |
| Neck Diameter (Decimal Inch) | 0.1280" |
| Neck Length (Decimal Inch) | 0.6250" |
| Neck Length (Inch) | 5/8" |
| Overall Length (Decimal Inch) | 2.5000" |
| Overall Length (Inch) | 2-1/2" |
| Radius (Decimal Inch) | 0.0470" |
| Radius (Inch) | 3/64" |
| Number of Flutes | 3 |
| Reach Multiple | 5x |
| Radius Center (Decimal Inch) | 0.1090" |
| Radius Center (Inch) | 7/64" |
| Shank Diameter (Decimal Inch) | 0.2500" |
| Shank Diameter (Inch) | 1/4" |
| Metric | No |
| Coating | AlTiN |
| Pilot Flare | 5 |
| Shoulder Flare | 5 |
| Single or Double Angle | Single |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Material:
Solid Carbide
Radius (Inch):
3/64"
Radius (Decimal Inch):
0.0470"
Mill Diameter (Inch):
1/4"
Mill Diameter (Decimal Inch):
0.2500"
Number of Flutes:
3
Finish/Coating:
AlTiN
Single or Double End:
Single
Overall Length (Inch):
2-1/2"
Overall Length (Decimal Inch):
2.5000"
Shank Diameter (Inch):
1/4"
Ships:
From Partner Facility
IsDiscontinued:
