| Head Diameter (Decimal Inch) | 1.0000" |
| Head Diameter (Inch) | 1" |
| Neck Diameter (Decimal Inch) | 0.4710" |
| Neck Length (Decimal Inch) | 1.5000" |
| Neck Length (Inch) | 1-1/2" |
| Overall Length (Decimal Inch) | 4.0000" |
| Overall Length (Inch) | 4" |
| Radius (Decimal Inch) | 0.2500" |
| Radius (Inch) | 1/4" |
| Number of Flutes | 4 |
| Shank Diameter (Decimal Inch) | 1.0000" |
| Shank Diameter (Inch) | 1" |
| Metric | No |
| Coating | AlTiN |
| Pilot Flare | 5 |
| Shoulder Flare | 5 |
| Single or Double Angle | Single |
