Product Specifications
| Mill Diameter (Decimal Inch) | 0.0620" |
| Mill Diameter (Inch) | 1/16" |
| Neck Diameter (Decimal Inch) | 0.0310" |
| Neck Diameter (Inch) | 1/32" |
| Cutter Width (Decimal Inch) | 0.0390" |
| Neck Length (Decimal Inch) | 0.0930" |
| Neck Length (Inch) | 3/32" |
| Overall Length (Decimal Inch) | 1.5000" |
| Overall Length (Inch) | 1-1/2" |
| Radial Depth Of Cut (Decimal Inch) | 0.0140" |
| Number of Flutes | 4 |
| Reach Multiple | 1.5x |
| Type | I |
| Shank Diameter (Decimal Inch) | 0.1250" |
| Shank Diameter (Inch) | 1/8" |
| Metric | No |
| Coating | Uncoated |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Cutting Diameter (Inch):
1/16"
Cutting Diameter (Decimal Inch):
0.0620"
Cutting Width (Decimal Inch):
0.0390"
Tooth Configuration:
Straight
Neck Length (Inch):
3/32"
Neck Length (Decimal Inch):
0.0930"
Material:
Carbide
Finish/Coating:
Uncoated
Shank Diameter (Inch):
1/8"
Shank Diameter (Decimal Inch):
0.1250"
Overall Length (Inch):
1-1/2"
Overall Length (Decimal Inch):
1.5000"
Ships:
From Partner Facility
IsDiscontinued:
