Harvey Tool 41024-C3 | 3/8" Diameter x 1" Flute Length x 3/8" Straight Shank x 2-1/2" OAL 140 Degree Included Angle AlTiN Coated Solid Carbide Spotting Drill

$73.10
Ships:
From Partner Facility
Brand:
Harvey Tool
Size (Inch):
3/8"
Size (Decimal Inch):
0.3750"
Drill Point Angle:
140 Degree
Flute Length (Inch):
1"
Flute Length (Decimal Inch):
1.0000"
Shank Diameter (Inch):
3/8"
Shank Diameter (Decimal Inch):
0.3750"
Shank Type:
Straight
Overall Length (Inch):
2-1/2"
Overall Length (Decimal Inch):
2.5000"
Finish/Coating:
AlTiN
Through Coolant:
No
Material:
Solid Carbide
Ships:
From Partner Facility
SKU:
10101524
UPC:
Weight:
0.12 LBS
Shipping:
Calculated at Checkout
Features
  • 90 Degree available in long length!
  • Thinned Web to Reduce Walking
  • Self-Centering Point Geometry
  • 2 Flutes
  • Solid Carbide
  • CNC ground in the USA
Product Specifications
Drill Diameter (Decimal Inch) 0.3750"
Drill Diameter (Inch) 3/8"
Angle Per Side 70 Degrees
Included Angle 140 Degree
Flute Length (Decimal Inch) 1.0000"
Flute Length (Inch) 1"
Shank Diameter (Decimal Inch) 0.3750"
Shank Diameter (Inch) 3/8"
Overall Length (Decimal Inch) 2.5000"
Overall Length (Inch) 2-1/2"
Finish/Coating AlTiN
Through Coolant No
Material Solid Carbide
Number of Flutes 2
LOC Multiple (3x)
Web Thickness (Decimal Inch) 0.0270"
Type II
Single or Double Single
