| Mill Diameter (Decimal Inch) | 0.3125" |
| Mill Diameter (Inch) | 5/16" |
| Neck Diameter (Decimal Inch) | 0.2010" |
| Length Of Cut (Decimal Inch) | 0.2660" |
| Neck Length (Decimal Inch) | 2.2500" |
| Neck Length (Inch) | 2-1/4" |
| Overall Reach (Decimal Inch) | 2.5160" |
| Overall Length (Decimal Inch) | 4.0000" |
| Overall Length (Inch) | 4" |
| Radius (Decimal Inch) | 0.1562" |
| Radius (Inch) | 5/32" |
| Wrap Angle | 270 Degree |
| Number of Flutes | 4 |
| Shank Diameter (Decimal Inch) | 0.3125" |
| Shank Diameter (Inch) | 5/16" |
| Coating | Uncoated |
