Product Specifications
| Head Diameter (Decimal Inch) | 0.0550" |
| Neck Diameter (Decimal Inch) | 0.0430" |
| Chamfer Center Diameter (Decimal Inch) | 0.0515" |
| Length Of Cut (Decimal Inch) | 0.0045" |
| Neck Length (Decimal Inch) | 0.4370" |
| Neck Length (Inch) | 7/16" |
| Overall Length (Decimal Inch) | 2.0000" |
| Overall Length (Inch) | 2" |
| Chamfer Center Length (Decimal Inch) | 0.0423" |
| End Length (Decimal Inch) | 0.0400" |
| Angle Per Side | 45 Degree |
| Included Angle | 90 Degree |
| Number of Flutes | 4 |
| Shank Diameter (Decimal Inch) | 0.1250" |
| Shank Diameter (Inch) | 1/8" |
| Metric | No |
| Coating | AlTiN |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Head Diameter (Decimal Inch):
0.0550"
Neck Length (Decimal Inch):
0.4370"
Number of Flutes:
4
Finish/Coating:
AlTiN
Material:
Solid Carbide
Ships:
From Partner Facility
interval quantity:
1
