Product Specifications
| Pilot Diameter (Decimal Inch) | 0.0200" |
| Neck Diameter (Inch) | 3/32" |
| Neck Diameter (Decimal Inch) | 0.0930" |
| Neck Length (Inch) | 3/4" |
| Neck Length (Decimal Inch) | 0.7500" |
| Overall Length (Inch) | 2" |
| Overall Length (Decimal Inch) | 2.0000" |
| Radius (Inch) | 1/32" |
| Radius (Decimal Inch) | 0.0310" |
| Number of Flutes | 2 |
| Reach Multiple | 8x |
| Shank Diameter (Inch) | 1/8" |
| Shank Diameter (Decimal Inch) | 0.1250" |
| Metric (Yes/No) | No |
| Center Cutting (Yes/No) | No |
| Chip Breaker (Yes/No) | No |
| Pilot Flare | 5 |
| Finish/Coating | AlTiN |
| Shoulder Flare | 5 |
| Double Ended (Yes/No) | No |
| Weldon Flat (Yes/No) | No |
| Coolant Through (Yes/No) | No |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Material:
Carbide
Radius (Inch):
1/32"
Radius (Decimal Inch):
0.0310"
Mill Diameter (Decimal Inch):
0.020"
Number of Flutes:
2
Finish/Coating:
AlTiN
Single or Double End:
Single
Overall Length (Inch):
2"
Overall Length (Decimal Inch):
2.0000"
Shank Diameter (Inch):
1/8"
Shank Diameter (Decimal Inch):
0.1250"
Ships:
From Partner Facility
