Harvey Tool 67708-C3 | 0.0580" Diameter x 5/16" Shank x 2-1/2" OAL 4 Flute AlTiN Coated Carbide Single End Corner Rounding End Mill

$128.70
Brand:
Harvey Tool
Pilot Diameter (Decimal Inch):
0.0580"
Radius (Inch):
1/8"
Radius (Decimal Inch):
0.1250"
Number of Flutes:
4
Finish/Coating:
C3
Single or Double End:
Double
Shank Diameter (Inch):
5/16"
Shank Diameter (Decimal Inch):
0.3125"
Shank Diameter (mm):
7.94mm
Length of Cut (Decimal Inch):
0.1300"
Overall Length (Inch):
2-1/2"
Overall Length (Decimal Inch):
2.5000"
SKU:
25187141
UPC:
Weight:
0.08 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
67708-C3

This Corner Rounding End Mills - 3 Flute - Flared Harvey Tool product selection features tooling with 5 Degree flares tangent at the pilot.

  • Single end
  • Cutting on radius and end only (not center cutting)
  • 5 Degree flares tangent at pilot and shoulder to avoid steps
  • Axial depth of cut = radius plus .005"
  • 3 flutes
  • Solid carbide
  • CNC ground in the USA

Product Specifications
Pilot Diameter (Inch)0.0580"
Length of Cut (Inch)0.1300"
Overall Length (Inch)2.5000" (2-1/2)
Radius0.1250" (1/8)
Number of Flutes4
Shank Diameter (Inch)0.3125" (5/16)
Coating/FinishC3
Pilot Flare5
Shoulder Flare5
Double EndedYes

Warning:

This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.

For more information, visit www.P65Warnings.ca.gov

Brand:
Harvey Tool
Pilot Diameter (Decimal Inch):
0.0580"
Radius (Inch):
1/8"
Radius (Decimal Inch):
0.1250"
Number of Flutes:
4
Finish/Coating:
C3
Single or Double End:
Double
Shank Diameter (Inch):
5/16"
Shank Diameter (Decimal Inch):
0.3125"
Shank Diameter (mm):
7.94mm
Length of Cut (Decimal Inch):
0.1300"
Overall Length (Inch):
2-1/2"
Overall Length (Decimal Inch):
2.5000"
