Product Specifications
| Manufacturer Part Number | 716310 |
| Cutter Diameter (Decimal Inch) | 0.140" |
| Cutter Diameter (Inch) | 9/64" |
| Neck Diameter (Decimal Inch) | 0.070" |
| Cutter Width (Decimal Inch) | 0.031" |
| Cutter Width (Inch) | 1/32" |
| Neck Length (Decimal Inch) | 0.203" |
| Neck Length (Inch) | 13/64" |
| Overall Length (Decimal Inch) | 2.000" |
| Overall Length (Inch) | 2" |
| Radial Depth of Cut (Decimal Inch) | 0.035" |
| Number of Flute | 6 |
| Reach Multiple | (1x) |
| Type | I |
| Shank Diameter (Decimal Inch) | 0.187" |
| Shank Diameter (Inch) | 3/16" |
| Metric | No |
| Coating | Uncoated |
| Product Type | Keyseat Cutter |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Cutting Diameter (Inch):
9/64"
Cutting Diameter (Decimal Inch):
0.1400"
Cutting Diameter (mm):
3.56mm
Cutting Width (Inch):
1/32"
Cutting Width (Decimal Inch):
0.0310"
Cutting Width (mm):
0.79mm
Neck Length (Inch):
13/64"
Neck Length (Decimal Inch):
0.2030"
Neck Length (mm):
5.16mm
Finish/Coating:
Uncoated
Shank Diameter (Inch):
3/16"
Shank Diameter (Decimal Inch):
0.1870"
Shank Diameter (mm):
4.75mm
Overall Length (Inch):
2"
Overall Length (Decimal Inch):
2.0000"
Overall Length (mm):
50.80mm
Interval quantity:
1
