Harvey Tool 772545 | 1/8" Shank 90 Degree Included Angle 2 Flute Uncoated Carbide Chamfer Mill

$35.50
Brand:
Harvey Tool
Neck Diameter (Decimal Inch):
0.0470"
Length of Cut (Decimal Inch):
0.0240"
Overall Reach (Decimal Inch):
0.2810"
Overall Length (Inch):
2-1/2"
Overall Length (Decimal Inch):
2.5000"
Included Angle:
90 Degree
Number of Flutes:
2
Shank Diameter (Inch):
1/8"
Shank Diameter (Decimal Inch):
0.1250"
Shank Diameter (mm):
3.18mm
Finish/Coating:
Uncoated
SKU:
25187010
UPC:
Weight:
1.23 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
772545

pointed, which is great for chamfering and deburring in small and narrow areas.

  • Pointed - 2 flute style for deburring and chamfering in narrow grooves, slots and small holes

Product Specifications
Neck Diameter (Inch)0.0470" (3/64)
Length of Cut (Inch)0.0240"
Overall Reach (Inch)0.2810" (9/32)
Overall Length (Inch)2.5000" (2-1/2)
Tip0.0050"
Number of Flutes2
Angle per Side45
Included Angle90
Reach Multiple6x
TypeI
Shank Diameter (Inch)0.1250" (1/8)
Coating/FinishUncoated

Warning:

This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.

For more information, visit www.P65Warnings.ca.gov

Brand:
Harvey Tool
Neck Diameter (Decimal Inch):
0.0470"
Length of Cut (Decimal Inch):
0.0240"
Overall Reach (Decimal Inch):
0.2810"
Overall Length (Inch):
2-1/2"
Overall Length (Decimal Inch):
2.5000"
Included Angle:
90 Degree
Number of Flutes:
2
Shank Diameter (Inch):
1/8"
Shank Diameter (Decimal Inch):
0.1250"
Shank Diameter (mm):
3.18mm
Finish/Coating:
Uncoated
