Product Specifications
| Drill Diameter (Inch) | 7/64" |
| Drill Diameter (Decimal Inch) | 0.1094" |
| Length of Cut (Decimal Inch) | 0.1820" |
| Drill Length (Inch) | 7/64" |
| Drill Length (Decimal Inch) | 0.1090" |
| Overall Length (Inch) | 2" |
| Overall Length (Decimal Inch) | 2.0000" |
| Angle per Side | 60 Degree |
| Included Angle | 120 Degree |
| Point Angle | 120 Degree |
| Number of Flutes | 2 |
| Size (Inch) | #3 |
| Shank Diameter (Inch) | 1/4" |
| Shank Diameter (Decimal Inch) | 0.2500" |
| Metric (Yes/No) | No |
| Center Cutting (Yes/No) | No |
| Chip Breaker (Yes/No) | No |
| Finish/Coating | AlTiN |
| Double Ended (Yes/No) | Yes |
| Weldon Flat (Yes/No) | No |
| Coolant Through (Yes/No) | No |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Material:
Carbide
Included Angle:
120 Degree
Trade Size:
3
Body Diameter (Inch):
7/64"
Body Diameter (Decimal Inch):
0.1094"
Number of Flutes:
2
Finish/Coating:
AlTiN
Overall Length (Inch):
2"
Overall Length (Decimal Inch):
2.0000"
Ships:
From Partner Facility
IsDiscontinued:
