Product Specifications
| Mill Diameter (Decimal Inch) | 0.1870" |
| Mill Diameter (Inch) | 3/16" |
| Neck Diameter (Decimal Inch) | 0.0620" |
| Neck Diameter (Inch) | 1/16" |
| Cutter Width (Decimal Inch) | 0.0620" |
| Cutter Width (Inch) | 1/16" |
| Neck Length (Decimal Inch) | 0.0930" |
| Neck Length (Inch) | 3/32" |
| Overall Length (Decimal Inch) | 2.0000" |
| Overall Length (Inch) | 2" |
| Radial Depth Of Cut (Decimal Inch) | 0.0520" |
| Corner Radius (Decimal Inch) | 0.0100" |
| Number of Flutes | 6 |
| Reach Multiple | (0.5x) |
| Type | II |
| Shank Diameter (Decimal Inch) | 0.1875" |
| Shank Diameter (Inch) | 3/16" |
| Coating | AlTiN |
| Top Corner Radius | 0.01 |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Milling Diameter (Inch):
3/16"
Milling Diameter (Decimal Inch):
0.1870"
Cutting Width (Inch):
1/16"
Cutting Width (Decimal Inch):
0.0620"
Corner Radius:
0.0100"
Neck Length (Inch):
3/32"
Neck Length (Decimal Inch):
0.0930"
Material:
Solid Carbide
Finish/Coating:
AlTiN
Shank Diameter (Inch):
3/16"
Shank Diameter (Decimal Inch):
0.1875"
Overall Length (Inch):
2"
Overall Length (Decimal Inch):
2.0000"
Tooth Configuration:
Straight
Ships:
From Partner Facility
