Harvey Tool 846205 | 0.1180" (3 mm) Diameter x 0.1250" (1/8) Shank x 0.3540" LOC x 2.5000" (2-1/2) OAL x 4 Flutes Uncoated Carbide Square End Mill

$43.30
Brand:
Harvey Tool
Neck Diameter (Decimal Inch):
0.1165"
Shank Diameter (Inch):
1/8"
Cutter Diameter (mm):
3.00mm
Length of Cut (Decimal Inch):
0.3540"
Overall Reach (Inch):
1-3/16"
Overall Reach (Decimal Inch):
1.1870"
Number of Flutes:
4
Finish/Coating:
Uncoated
Neck Length (Decimal Inch):
0.8330"
Shank Diameter (Decimal Inch):
0.1250"
Shank Diameter (mm):
3.18mm
Overall Length (Inch):
2-1/2"
Overall Length (Decimal Inch):
2.5000"
interval quantity:
1
SKU:
25211565
UPC:
Weight:
0.03 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout

Miniature End Mills - Square - Long Reach, Standard Flute feature a reduced neck diameter to avoid heeling.

  • CNC ground in the USA
  • Center Cutting
  • Solid Carbide

Product Specifications
Tool Number846205
Cutter Diameter (Inch)0.1180" (3 mm)
Neck Diameter (Inch)0.1165"
Length of Cut (Inch)0.3540"
Neck Length (Inch)0.8330"
Overall Reach (Inch)1.1870" (1-3/16)
Overall Length (Inch)2.5000" (2-1/2)
Flutes4
LOC Multiple3x
Reach Multiple10x
Shank Diameter (Inch)0.1250" (1/8)
CoatingUncoated
