| Cutter Diameter (Inch) | 3/16" |
| Cutter Diameter (Decimal Inch) | 0.1875" |
| Neck Diameter (Decimal Inch) | 0.1170" |
| Length of Cut (Decimal Inch) | 0.1600" |
| Neck Length (Inch) | 7/8" |
| Neck Length (Decimal Inch) | 0.8750" |
| Overall Reach (Decimal Inch) | 1.0350" |
| Overall Length (Inch) | 3" |
| Overall Length (Decimal Inch) | 3.0000" |
| Radius (Decimal Inch) | 0.0938" |
| Wrap Angle | 270 Degree |
| Number of Flutes | 4 |
| Shank Diameter (Inch) | 3/16" |
| Shank Diameter (Decimal Inch) | 0.1875" |
| Metric (Yes/No) | No |
| Center Cutting (Yes/No) | No |
| Chip Breaker (Yes/No) | No |
| Finish/Coating | Uncoated |
| Double Ended (Yes/No) | No |
| Weldon Flat (Yes/No) | No |
| Coolant Through (Yes/No) | No |
