| Head Diameter (Decimal Inch) | 0.1650" |
| Neck Diameter (Decimal Inch) | 0.1010" |
| Length of Cut (Decimal Inch) | 0.0290" |
| Neck Length (Inch) | 5/32" |
| Neck Length (Decimal Inch) | 0.1560" |
| Overall Length (Inch) | 2" |
| Overall Length (Decimal Inch) | 2.0000" |
| Angle per Side | 45 Degree |
| Included Angle | 90 Degree |
| Number of Flutes | 5 |
| Reach Multiple | 1.5x |
| Shank Diameter (Inch) | 3/16" |
| Shank Diameter (Decimal Inch) | 0.1875" |
| Metric (Yes/No) | No |
| Center Cutting (Yes/No) | No |
| Chip Breaker (Yes/No) | No |
| Finish/Coating | AlTiN |
| Double Ended (Yes/No) | No |
| Weldon Flat (Yes/No) | No |
| Coolant Through (Yes/No) | No |
