Product Specifications
| Mill Diameter (Inch) | 3/32" |
| Mill Diameter (Decimal Inch) | 0.0930" |
| Number of Flutes | 2 |
| Finish/Coating | AlTiN Nano |
| Length Of Cut (Inch) | 9/64" |
| Length Of Cut (Decimal Inch) | 0.1400" |
| Overall Reach (Inch) | 2" |
| Overall Reach (Decimal Inch) | 2.0000" |
| Overall Length (Inch) | 4" |
| Overall Length (Decimal Inch) | 4.0000" |
| Shank Diameter (Inch) | 1/4" |
| Shank Diameter (Decimal Inch) | 0.2500" |
| Center Cutting (Yes/No) | Yes |
| Neck Diameter (Decimal Inch) | 0.1910" |
| Minor Diameter (Decimal Inch) | 0.0850" |
| Neck Length | 0.1395" |
| Tapered Reach (Decimal Inch) | 1.7500" |
| Tapered Reach (Inch) | 1-3/4" |
| Neck Angle | 2 |
| LOC Multiple | 1.5x |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Mill Diameter (Inch):
3/32"
Mill Diameter (Decimal Inch):
0.0930"
Number of Flutes:
2
Material:
Carbide
Finish/Coating:
AlTiN Nano
Length of Cut (Inch):
9/64"
Length of Cut (Decimal Inch):
0.1400"
Shank Type:
Reduced
Overall Reach (Inch):
2"
Overall Reach (Decimal Inch):
2.0000"
Overall Length (Inch):
4"
Overall Length (Decimal Inch):
4.0000"
Shank Diameter (Inch):
1/4"
Shank Diameter (Decimal Inch):
0.2500"
Single or Double End:
Single
Center Cutting:
Yes
Cutting Direction:
Right
Ships:
From Partner Facility
