Product Specifications
| Mill Diameter (Inch) | 1/4" |
| Mill Diameter (Decimal Inch) | 0.2500" |
| Corner Radius (Decimal Inch) | 0.0050" |
| Number of Flutes | 4 |
| Finish/Coating | AlTiN |
| Length Of Cut (Inch) | 1-1/4" |
| Length Of Cut (Decimal Inch) | 1.2500" |
| Overall Length (Inch) | 4" |
| Overall Length (Decimal Inch) | 4.0000" |
| Shank Diameter (Inch) | 1/4" |
| Shank Diameter (Decimal Inch) | 0.2500" |
| Single or Double End | Single |
| Center Cutting (Yes/No) | No |
| LOC Multiple | 5x |
| Chip Breaker (Yes/No) | No |
| Weldon | No |
| Coolant Through (Yes/No) | No |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Mill Diameter (Inch):
1/4"
Mill Diameter (Decimal Inch):
0.2500"
End Type:
Radius
Corner Radius (Decimal Inch):
0.0050"
Number of Flutes:
4
Material:
Carbide
Finish/Coating:
AlTiN
Length of Cut (Inch):
1-1/4"
Length of Cut (Decimal Inch):
1.2500"
Shank Type:
Straight
Overall Length (Inch):
4"
Overall Length (Decimal Inch):
4.0000"
Shank Diameter (Inch):
1/4"
Shank Diameter (Decimal Inch):
0.2500"
Single or Double End:
Single
Center Cutting:
No
Cutting Direction:
Right
Ships:
From Partner Facility
